HUAWEI eKitEngine S380-S8P2T : Multi-Service Gateway : 2*GE WAN, 8*GE LAN(PoE+, 124W), up to 250 users, forwarding performance 2 Gbit/s BY BILLIONAIRE SECURETECH S380-S8P2T

Huawei eKitEngine

S380-S8P2T

Multi Service Gateway

2*GE WAN, 8*GE LAN(PoE+, 124W), up to 250 users,

forwarding performance 2 Gbit/s

Description :

Multi-Service Gateway | Number of managed Aps: 64 | Maximum user: 300 | Switching Capacity: 16Gbps | Packet forwarding rate: Upload:500 Kpps, download:420 Kpps | Egress bandwidth: 2Gbps | 2 x 10/100/1000BASE-T ports, 1 x GE SFP port(WLAN) + 8 x 10/100/1000BASE-T ports(LAN) | PoE+

Features :

Users:250

Switching Capacity: 16 Gbps

Packet Forwarding Rate: (Upload: 500 Kpps) (Download: 420 Kpps)

Egress Bandwidth: 2 Gbit/s

Fixed WAN Ports: 2 x 10/100/1000BASE-T ports

Fixed LAN Ports: 8 x 10/100/1000BASE-T ports

MAC Address Entry: 2K

Chassis Dimensions (H x W x D): 35 mm x 210 mm x 130 mm

Chassis Height: 1 U

Weight: 0.7 kg

Power Module Type: Power adapter

PSU Rated Input Voltage: AC input: 100 V AC to 240 V AC, 50/60 Hz

PSU Input Voltage Range: AC input: 90 V AC to 290 V AC, 47 Hz to 63 Hz

Max Power Consumption Without PoE: 21.8 W

Max Power Consumption With PoE: 145.8 W

Long-term Operating Temperature: 0°C to 40°C (0 m to 1800 m)

Storage Temperature: –40°C to +70°C

Relative Humidity: 5% to 95% (non-condensing)

Heat Dissipation Mode: Natural heat dissipation
